Product Details

HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area
Variable-speed swing compressors. Quiet digitally commutated fan motor. High-density compressor sound blanket
Compatible with Goodman connected thermostat and other Goodman communicating equipment. Proprietary control algorithmic logic
In communicating mode, only two low-voltage wires to outdoor unit required
Diagnostic indicator lights, seven-segment LED display, and fault code storage. Proprietary Inside intelligence for diagnostics
Field-selectable boost mode increases compressor speed during unusually high loads. Field-installed Bi-flow filter drier
Coil and ambient temperature sensors. Suction pressure transducer. Quiet-mode - provides enhanced acoustical comfort, up to 3 different sound levels (as low as 45 dBA). Sweat connection service valves with easy access to gauge ports
AHRI certified. ETL listed
Heavy-gauge galvanized steel cabinet with grille-style sound control side design. Custom ivory white powder-paint finish. High corrosion-resistant (ZAM®), unpainted steel bottom frame and legs
500-hour salt-spray tested. Wire fan discharge grille. Top and side maintenance access. When properly anchored, meets the 2020 Florida building code unit integrity requirements for hurricane-type winds (anchor bracket kits available)

Specifications

AMP: 1.15, 13.4, 18.8

BTU: 24000

BTU Cooling Rating: 22200 Btu/h

BTU Heat Rating: 23200 Btu/h

Collection: GSZS6

Communicating: Communicating

Compressor Type: Swing

Decibel Rating (dB): 67 dB

Depth: 13-3/4 in

EER2: 10.1

EER2 Range: 0 - 10.5

ETL Listed: Yes

Energy Star Compliant: No

Factory Std. Refrigerant Charge: 81 oz

HSPF2: 8.5

HSPF2 Range: 7.5 - 25.0

Height: 27-3/8 in

Horsepower: 9/100 hp

Liquid Line (OD): 3/8 in

MBH: 24

Max Fuse Size: 20

Phase: Single Phase

Power Source: Electric

Refrigerant: R-410A

Refrigeration Control Type: EEV

SEER: 16.2

SEER2: 17.2

SEER2 Range: 15.2 - 40.0

Sound Blanket: Yes

Suction Line (OD): 3/4 in

Tonnage: 2 Ton

Volts: 208/230V

Width: 36-5/8 in
Conclusion

In summary, the Goodman GSZ-S6 heat pump series is an excellent choice for homeowners seeking a reliable, energy-efficient heating and cooling solution. With its durable construction, advanced comfort features, and robust warranty options, it provides a compelling balance of performance and value. Whether used in a single-family home or a larger residence, the GSZ-S6 can help maintain a comfortable indoor climate year-round, making it a top pick for both new installations and replacements of older systems.

For more detailed specifications, features, and pricing, you can visit Goodman's official website or consult local HVAC suppliers for personalized recommendations.

Goodman GZS6 Series – Efficient Comfort for Your Home

Introducing the Goodman GZS6 Series, a top-of-the-line HVAC system designed to deliver optimal comfort and energy efficiency for your home. With advanced technology and robust construction, this unit is built to keep your living space comfortable year-round while being mindful of your energy consumption.

Key Features

High Energy Efficiency: The GZS6 Series boasts an impressive SEER (Seasonal Energy Efficiency Ratio) rating, ensuring that you receive high-efficiency cooling and heating without skyrocketing energy bills. This energy-efficient system not only helps reduce your carbon footprint but also saves you money on utility expenses.

Durable Construction: Crafted with quality materials, the GZS6 Series is designed to withstand harsh weather conditions and provide reliable performance for years to come. Its galvanized steel cabinet with a baked enamel finish protects against corrosion, ensuring long-lasting durability and aesthetic appeal.

Advanced Compressor Technology: The Goodman GZS6 is equipped with a high-efficiency scroll compressor, which operates quietly and efficiently. This technology provides consistent cooling and heating, ensuring a comfortable environment in your home without excessive noise.

Variable-Speed Blower: The variable-speed blower enhances airflow control and comfort by adjusting to the cooling or heating demands of your home. This feature not only optimizes your indoor climate but also improves energy efficiency and reduces energy costs.

Smart Technology Integration: The GZS6 Series is compatible with smart thermostats, allowing you to control your HVAC system remotely. Enjoy the convenience of adjusting your home's temperature settings from your smartphone, ensuring comfort when you arrive home.

Easy Maintenance: With a user-friendly design, the GZS6 Series makes maintenance straightforward. The easily accessible filter and service panel allow for quick filter changes and servicing, helping you maintain optimal performance and efficiency throughout the year.

Conclusion: Invest in Your Comfort Today

The Goodman GZS6 Series is the ideal choice for homeowners looking for a reliable, energy-efficient, and high-performance HVAC solution. With its advanced features, durable construction, and quiet operation, this system offers the perfect balance of comfort and efficiency.

Transform your living environment and enjoy peace of mind knowing that you have a top-notch HVAC system working tirelessly to keep your home comfortable year-round. Make the smart choice for your home today with the Goodman GZS6 Series and experience the difference in quality and performance

Benefits of the Goodman GZS6 Series

Enhanced Comfort Levels: Experience consistent and reliable heating and cooling, ensuring that every room in your home maintains the desired temperature. The GZS6 Series provides balanced airflow, preventing hot or cold spots in your living space.

Lower Energy Bills: The high-efficiency design of the GZS6 Series helps you save on energy costs while providing optimal comfort. Enjoy the peace of mind that comes with knowing your HVAC system is working efficiently to minimize your utility bills.

Environmentally Friendly: By reducing energy consumption, the Goodman GZS6 Series contributes to a more sustainable environment. Enjoy a comfortable home while being eco-conscious and reducing your overall carbon footprint.

Quiet Operation: Thanks to its advanced compressor technology and variable-speed blower, the GZS6 operates quietly, ensuring that your home remains a peaceful haven. Enjoy comfort without disruptive noise, making it perfect for any living space.

Reliable Performance: Goodman is known for its commitment to quality and reliability, and the GZS6 Series is no exception. With a robust design and exceptional warranty options, you can trust that your HVAC system will provide years of dependable service.
